Welcome to the Future of High-Efficiency Mammalian Cell Culture: Introducing the Stainless Steel Mammalian Cell Bioreactor BLBIO-SCUC

You cannot make trade-offs when your work is based on delicate mammalian or animal cells. Cell shearing, contamination and inconsistency in the process can cost you days, if not weeks. But what are you to do when you need to do it all–and when you need the consistent precision of reproducible, re-scalable results?

Let’s explore why the stainless steel mammalian cell bioreactor is the bioreactor you’ve been waiting for.

Cutting-Edge Engineering for Demanding Applications

Set to provide the best conditions to sensitive mammalian and animal cells, this bioreactor is an amalgamation of the ability of stainless steel to perform reliably with the progressive control systems. Whether on CHO cells and hybridisms, insect cells and others, this solution simply integrates into your custom culture requirements.

Do you need gentle mixing? Precise gas control? Automated sterilization? The Stainless steel mammalian cell bioreactor integrates all of these and more into a single, user-friendly system.

Why Choose the Stainless Steel Mammalian Cell Bioreactor?

Your lab or production facility deserves a system that:

• Uses the highest grade stainless steel (316L for tank, 304 for clamp materials).
• Guarantees zero blind angles and dead zones.
• Has own low-shear magnetic drive system-perfect with delicate suspending cells.
• Offers in-situ sterilization and cleaning.
• Enables accurate temperature, pH, DO and gas flow control.
• Is user friendly and operates with a Siemens Touch screen and PLC interface.

It can be all with a modular design that fits your process in the present and is easily expanded as your requirements increase in the future.

Detailed Technical Specifications: A Closer Look

Here’s exactly what makes this system a top performer:

Parameter	Description
Total volume	5L,10L,15L,20L,30L,50L,100L,200L,500L,1000L, 5KL, 10KL etc.
Working volume	30%~70%
Tank	Inside electrolytic polishing, precision: 0.2-0.4um. Diameter and height ratio 1:1.5
Stirring system	Magnetic drive, low shear mixing blades. Stir speed: 30~300rpm
Sterilization	Sterilize in place (SIP), auto control by program
Clean	Clean in place by spray ball
Gas control	Provision for mixing at least four gases (Air, Oxygen, Nitrogen and CO2) Auto control by mass flow meter. Air flow 1vvm, O2/N2/CO2  0.1vvm.
Feeding	Automatically feeding by peristaltic pump
Anti-foam control	Automatically add antifoamer by peristaltic pump
Temperature control	Auto-control, electric heating range: water source add 5℃ to 70℃
PH control	PH 2.00-12.00±0.1, auto-control adding acid/base by peristaltic pump, pH sensor from Hamilton/Mettler, Switzerland.
Do control	0-150±3% displaying precision 0.1%, DO sensor from Hamilton/Mettler, Switzerland. DO coupling with agitation, oxygen.
Sampling valve	Can sterilization separately, manual
Harvest	Zero dead zone bottom valve, can sterilization separately, manual
Weight system	Mettler-Toledo, Switzerland
Pressure	Auto control, BD Germany pressure transmitter or Lambert differential pressure liquid level gauge.
Exhaust	Have condenser before exhaust, control by diagram valve / Proportional control valve.
Control parameters	10 or 15 inch touch screen, Siemens PLC with control parameters (stirring, pH, DO, temperature, feeding, alarm, gas etc.), data analysis, data record, data output, language(RU/EN/CN) and other customized functions
Optional configuration	Remote control, Mass flow meter(auto control gas), exhaust heating, exhaust filter, gas(CO2) exhaust analysis, Level sensor, Turbidity(OD) sensor, ORP sensor, Weight system, Live cell sensor（Biomass）, Printing, Siemens touch screen, Double mechanical seal, 4-valves-group for feeding, Bottom valve auto, ASME certificate, CSA certificate, air flow 2vvm, etc.

Practical Features that Solve Real Problems

Have you struggled with contamination issues or inconsistent yields? The stainless steel mammalian cell bioreactor solves these problems with:

• Smooth interior without blind corners- no more accumulation points of contaminants.
• The processing without dismantling of SIP and CIP systems sterilizing and cleaning.
• Efficient gas mixing of Air, O2, N2 and CO2 to give your cultures exactly what they require.
• Special designed exhaust systems that do not lose the organics and that experience contamination.
• Imagine having that level of assurance in every run.

External and Internal Design: Practical and Durable

Externally polished and internally smooth, the tank features:

• Large sight glasses for real-time liquid level monitoring.
• Philips safety sight lamp for clear observation.
• Side ports for pH, DO, and temperature sensors.
• Clip material in 304 stainless steel for robust support.
• Design pressure of up to 0.3 Mpa so you will not lose sleep even on a big scale.

This is quality engineering that is meant to deal with actual challenges of industrial biotech.

Low Shear Mixing: Gentle and Effective

Have you ever wondered what will happen when you over stir mammalian cells? They break down and your yield plummets.

The stainless steel mammalian cell bioreactor addresses this with a magnetic drive low-shear mixing system. This advanced system will not cause cell stress as seen with conventional mechanical stirrers, so you can achieve higher cell viability and productivity because mixing efficiency is maintained.

Your fragile CHO or hybridism cultures deserve nothing less.

Powerful Yet Intuitive Control System

Even a powerful bioreactor is of no use unless tightly controlled with an easy user interface. It is because of this that this system includes a Siemens S7-200 PLC as well as a color touch screen interface.

Operators can:

• Observe pH, DO, temperature, gas flow, pressure and stirrer speed continuously.
• Easily calibrate pH and DO probes.
• Analyze trends with built-in historical curve functions.
• Automate feeding, sterilization, and antifoam addition.
• Export information and merge with the upstream or downstream process applications.

It’s everything you need, accessible at a glance.

Applications: From Research to Full-Scale Production

The stainless steel mammalian cell bioreactor is more than a lab tool. It’s a bridge to commercial success:

• Ideal for culturing hybridoma, CHO, and insect cells.
• Accommodates serum-free suspension, high-density feeding and perfusion.
• Reputable in the production of monoclonal antibodies, recombinant proteins, viral vaccines as well as other high-end bio products.
• Its layout incorporates all the fundamental technologies required in so-called large-scale culture: cell line expansion, continuous perfusion and downstream viral harvest.

How much more production runs would you be able to optimize with that?

A Flexible, Future-Proof Solution

This bioreactor has the ability to grow in capacity with you whether you want to expand your university or commercial facility:

• Install optional modules as required-mass flow meters, biomass sensors or exhaust filtration.
• To meet the standards of regional GMP, to have the ASME and CSA certification.
• Expand capacity without redesigning your entire system.

This is an investment that never goes out of date with the maturity of your research.

Why Mammalian Cell Culture Demands This Level of Care

Mammalian cells are complex living factories. They need:

• Tight control of temperature, pH, and DO.
• Low shear stress to stay viable.
• High sterility to prevent contamination.
• Consistent gas mixing for ideal metabolic conditions.

A simple fermenter can’t do this reliably. The stainless steel mammalian cell bioreactor was engineered specifically to handle these challenges, so you get predictable, repeatable results batch after batch.

Make Downtime a Thing of the Past

Time is money in biotech. That’s why:

• Sterilize-in-place (SIP) saves days compared to manual cleaning.
• Clean-in-place (CIP) means faster changeovers.
• Remote monitoring and data logging reduce operator error.

There is no reason to put your company at risk of expensive contamination or interrupted service when your system can now work with you, rather than against you?

Trusted Engineering, Proven Performance

BaiLun Bio equipment is chosen by thousands of researchers and bio production facilities, as it is produced on the highest level:

• Premium Swiss sensors from Hamilton and Mettler.
• Siemens industrial automation for robust control.
• German-made pressure and weight systems for reliability.
• 316L stainless steel for industry-leading purity.

So why use anything less when your production is based on your bioreactor?

Your Next Step to Biotech Success

In your mammalian cell culture process every step should make you one step closer to succeed. The stainless steel mammalian cell bioreactor is designed to make that journey smoother, safer, and faster.

Call us now to get a detailed quote or talk with an expert that has an in-depth knowledge of your application.

Are you ready to transform your cell culture operations?

Let’s build the future of biotechnology, together, with the stainless steel mammalian cell bioreactor leading the way.
