Stirred Tank Bioreactor Manufacturer for Fermentation & Cell Culture
25+ Years Manufacturer
Export to 30+ Countries
CE / ISO / ASME Certified
OEM for Global Biotech Brands
Our Stirred Tank Bioreactor Solutions
We offer bioreactors (fermenters), animal cell bioreactors, bioreactor shakers, biological shakers, bottle rockers, and control systems, and recognize validation services are essential for meeting regulatory and operational requirements of fermenters and bioreactors.
Efficient Mixing Performance
High-efficiency impeller design
Excellent oxygen mass transfer
Uniform nutrient distribution
Precise Process Control
Advanced PID automatic control
Real-time pH / DO monitoring
Stable temperature & agitation control
Flexible Configuration
Multiple impeller options
Glass or stainless steel vessels
Lab, pilot, and industrial scale available
GMP & Sterile Design
SIP / CIP systems optional
Aseptic sampling & feeding
GMP-oriented hygienic structure
Premium Materials & Structure
High borosilicate glass or SUS316L vessel
Corrosion-resistant framework
Durable industrial-grade construction
Smart Automation System
Siemens PLC touch screen
SCADA remote monitoring optional
Data logging & recipe management
Stirred Tank Bioreactor Applications
We offer bioreactors (fermenters), animal cell bioreactors, bioreactor shakers, biological shakers, bottle rockers, and control systems, and recognize validation services are essential for meeting regulatory and operational requirements of fermenters and bioreactors.
| Parameter | Description |
| Total volume | Stainless steel bioreactor 5L~200KL,glass bioreactor 0.2L~40L |
| Working volume | 30%~70% |
| Tank | Stainless steel bioreactor：Jacket tank, made by SS316 and SS304, tank design pressure 0.3Mpa, jacket design pressure 0.35Mpa, polishing 0.4-0.6um, ratio of diameter and height is 1:2.2-2.5Glass bioreactor：Single glass vessel with stainless steel bottom. Lid made by stainless steel 316L with ports, condenser on the cover |
| Stirring system | Mechanical drive on the top/bottom or Magnetic drive on the top, 3pcs height adjustable six-blade paddleStir speed: 50~1000rpm/50-500rpm |
| Sterilization | Stainless steel bioreactor sterilize in place(SIP), auto control by program;Glass bioreactor off-site sterilization (Autoclave) |
| Clean | Stainless steel bioreactor Clean in place (CIP) by spray ball |
| Gas control | Control by rotor meter, air flow 1 vvm/2 vvm |
| Feeding | Automatically feeding by peristaltic pump |
| Anti-foam control | Automatically add antifoam by peristaltic pump |
| Temperature control | Auto-control, electric heating range: water source add 5℃ to 70℃ |
| PH control | PH 2.00-12.00±0.1, auto-control adding acid/base by peristaltic pump, pH sensor from Hamilton/Mettler, Switzerland. |
| Do control | 0-150±3% displaying precision 0.1%, DO sensor from Hamilton/Mettler, Switzerland. DO coupling with agitation, oxygen. |
| Sampling | Sampling valve, can sterilization separately, manual |
| Harvest | Stainless steel bioreactor zero dead zone bottom valve(Gemu/Burket,Germany), can sterilization separately, manual/auto |
| Lid lift system | Stainless steel bioreactor 30L-500L have lid lift system, 700-1000L have human hole. |
| Pressure | Stainless steel bioreactor auto control, BD Germany pressure transmitter |
| Exhaust | Stainless steel bioreactor have condenser before exhaust, control by diagram valve / Proportional control valve. |
| Control parameters | 10 or 15 inch touch screen , Siemens PLC with control parameters (stirring, pH, DO, temperature, feeding, alarm, gas etc.), data analysis, data record, data output, language(RU/EN/CN) and other customized functions |
| Optional configuration | Remote control, Mass flow meter(auto control gas), O2/N2/CO2, gas flow 2vvm, gas(CO2) exhaust analysis, Level sensor, Turbidity(OD) sensor, ORP sensor, Weight system, Live cell sensor(Biomass), Printing, Siemens touch screen, Double mechanical seal, 4-Valves-group for feeding, Bottom valve auto discharge, ASME certificate, CSA certificate, Batch culture, Seed transfer, etc. |
Why Not Other Suppliers
Customer Projects
Laboratory Research
Biotech Startup
Biological Agricultural Enterprise
Biotechnology R&D Company
