3L Parallel Glass Bioreactor System – Four Vessels for Laboratory Research

Bailun’s 3L Parallel Glass Bioreactor System with Four Vessels is designed for laboratory-scale parallel fermentation and cell culture studies. Featuring Four independent 3L borosilicate glass vessels, precise environmental control, and a compact benchtop design, the system allows simultaneous cultivation under uniform conditions. It is ideal for microbial, mammalian, and algae cell culture research, as well as early-stage bioprocess development and laboratory optimization.

This Four-vessel system is widely used in biotechnology laboratories, pharmaceutical R&D centers, academic institutions, and pilot-scale projects to enhance experimental throughput, reproducibility, and operational efficiency.

Applications of 3L Parallel Glass Bioreactor System – Four Vessels

The 3L Four-vessel bioreactor is suitable for a wide range of laboratory applications:

• Microbial Fermentation

• Mammalian Cell Culture

• Yeast and Bacterial Cultivation

• Suspension Cell Culture

• Recombinant Protein Expression

• Enzyme Production

• Algae Cultivation

• Bioprocess Development and Optimization

• Vaccine Research

• Academic Laboratory Studies

Researchers can run Four experiments simultaneously, increasing laboratory efficiency and ensuring consistent experimental outcomes.

Advantages of Four-Vessel Parallel Bioreactor Technology

Parallel Cultivation Design

Each vessel operates independently with uniform control, allowing simultaneous experiments under precise conditions.

Benefits include:

• Increased experimental throughput

• Consistent cultivation conditions across all vessels

• Efficient process comparison

• Reduced variability between runs

Each vessel separate and independent control.

Ideal for laboratory R&D, process screening, and bioprocess optimization studies.

High-Quality Borosilicate Glass Vessels

All 4 vessels are made of premium borosilicate glass for chemical resistance and visual monitoring.

Advantages include:

• High transparency for easy observation

• Excellent corrosion resistance

• Durable and long-lasting

• Easy cleaning and sterilization

Researchers can monitor microbial or mammalian cell growth directly in each vessel.

Precise Environmental Control

Each vessel has independent monitoring and control of critical parameters:

• Temperature

• pH

• Dissolved Oxygen (DO)

• Agitation speed

• Airflow

• Foam level

This ensures stable and reproducible cultivation conditions across all Four vessels.

Compact Laboratory Benchtop Design

The system is designed for efficient laboratory operation with minimal space requirements.

Benefits include:

• Space-saving structure

• Easy installation

• Convenient operation

• Flexible integration into laboratory workflows

Perfect for academic, industrial, and biopharma laboratories.

Key Features of Bailun 3L Parallel Glass Bioreactor – 4 Vessels

Four Independent Glass Vessels

• 3L borosilicate glass per vessel

• Single wall design for each vessel

• Heating by bottom stainless steel jacket

• Heating system

• Easy sterilization and cleaning

• High chemical resistance

• Compact benchtop footprint

Intelligent Control System

• PLC or HMI touchscreen optional

• Real-time monitoring for each vessel

• Data recording and batch reports

• Alarm and trend analysis functions

Optimized Agitation & Aeration

• Low-shear impeller design

• Independent agitation control for each vessel

• Uniform nutrient and oxygen distribution

• Adjustable airflow and aeration for each vessel

Sterility and Contamination Control

• Autoclavable glass vessels

• Sterile gas filtration

• Aseptic sampling ports

• Closed cultivation system

• Reduced contamination risk for parallel experiments

Customizable Four-Vessel Bioreactor Solutions

Bailun provides fully customizable solutions based on specific laboratory requirements:

Vessel Options

• Single wall borosilicate glass

• Jacketed glass for temperature control

• Hybrid glass-stainless design

Agitation Options

• Rushton impeller

• Marine impeller

• Paddle impeller

• Low-shear mixing

Sensor Options

• Turbidity OD

• ORP sensor

• Biomass living cell sensor

• Level sensor

• CO2 sensor

Automation Expansion

• PLC automation

• SCADA system

• Data logging

• Remote monitoring

• Gas CO2/N2/O2/Air/CO/H2

Advantages of Bailun Four-Vessel Bioreactor Systems

• High experimental throughput with Four parallel vessels

• Consistent and reproducible cultivation conditions

• Flexible customization for laboratory research needs

• Optimized for microbial, mammalian, and algae cell culture

• Global technical support for installation and operation

• Suitable for academic, industrial, and biopharma laboratories

Technical Specifications of 3L Parallel Glass Bioreactor – Four Vessels

Why Choose Bailun

Bailun is a professional manufacturer of laboratory parallel bioreactors for microbial, mammalian, and algae cell culture applications.

Advantages include:

• High-quality construction and materials

• Precision environmental control

• Compact and flexible laboratory design

• Customizable configurations for research needs

• Global technical support and service

Frequently Asked Questions

What is the main application of a 3L Four-vessel bioreactor?

The system is mainly used for parallel laboratory-scale microbial fermentation, mammalian cell culture, and bioprocess development research.

Can the vessels operate independently?

Yes. Each of the Four vessels has independent control of temperature, DO, pH, and agitation.

How is sterilization achieved?

All vessels are autoclavable and can be sterilized prior to operation to maintain aseptic conditions.

Can it support microbial and mammalian cell culture?

Yes. The system is optimized for microbial fermentation, mammalian suspension cell culture, and algae cultivation.

Can the bioreactor be customized?

Yes. Bailun provides vessel, agitation, sensor, and automation customization based on specific laboratory research requirements.

Request a Quote

Looking for a reliable 3L parallel glass bioreactor system with Four vessels?

Contact Bailun today for:

• Customized Four-vessel bioreactor solutions

• Technical consultation

• Detailed quotation

• Laboratory process support

• Global technical services

Our engineering team is ready to support your parallel cultivation and bioprocess research projects worldwide.
